Let’s TAC™ About It: Verified Templates: Balancing Security and Flexibility

For the tenth installment of our blog series, we will cover how TAC™ contracts can control what kinds of queries an analyst can ask. So, are you ready to TAC™ about it?

In our last Let’s TAC™ About It blog post, we gave a brief overview of how smart contracts work in TAC™. In addition to timing and user role, TAC™ contracts can also control what kinds of queries an authorized analyst can ask of the data. Arguably, this is the most unique and valuable feature in TAC™.

We have three methods. On one extreme, TAC™ can do this through Verified Scripts. This provides strong data control but limited analyst flexibility. Any analysis code is reviewed and pre-approved. The limitation is that this requires a manual review and approval process for each script. This is most useful for common and frequently performed analysis. VIA provides a number of Verified Scripts (e.g., descriptive statistics like max, min, etc.) by default.

On the other extreme, we have Free Form Python (FFPy). In this scenario, anything an analyst can ask in Python code (including “send me all the data” kind of queries) is permitted. This is terrific for analyst flexibility but has limited data protection for Data Owners (DOs). Internal power users are the main audience for this method.

What if you need something in-between? This is the most common scenario and hardest to solve for.

Here, TAC™ uses Verified Templates (VTs). DOs use VTs to set boundaries about what analysts can and cannot do. Within those boundaries, analysts have great flexibility. In short, each VT has two parts. The “end of a Python module” is written or agreed to by the DO and sets the boundaries. It is immutable. The second part, the header of the module, is filled in by the analyst. The VT can even include variables that are not defined. These provide entry points that must be fully defined to control the workflow before running. Any file where the end of the Python module matches the VT exactly (other than newlines and comments), constitutes a validated instance of the template.

This is an example VT:

def main(db, tables, results_path):
   print(hello_world)
   return []

The variable hello_world is highlighted because it is not defined by the template, thus providing flexibility to an analyst.

Then, the following query is a valid instance of the template:

hello_world='Welcome to TAC!'
def main(db, tables, results_path):
   print(hello_world)
   return []

and the following query is an invalid instance of the template:

def main(db, tables, results_path):
   print('Welcome to TAC!')
   return []

As this example shows, the VT must include the main function. Once an analyst changes the body of the main function or any other functions defined in the template, their query will be rejected by TAC™ and not sent to a DO’s data to run.

Sophisticated DOs can create an infinite number of VTs to suit their specific needs. VIA also has predefined VTs for specific use cases such as 15/15 for utility meter data analysis.

A hash of the DOs VT is stored in the smart contract and must be verified to execute. The VTs themselves can be stored on or off the blockchain. A combination of off-chain VT storage and on-chain hash is a common practice for privacy reasons.

Customers have been testing VTs on TAC™ for the past few months and we have been very pleased with the results so far. Balancing security and flexibility is a hard but universal challenge. We’re excited to have found a relatively high performance solution for the utility industry.
